2.4 Rotational Isomeric States

2.4.1 The Ising Chain

The rotational isomeric state model provides a direct map between calculation of polymer conformations and the familiar 1D Ising model. In this frame, we consider the energy of the chain as

    ∑n
U =     u(φi-1,φi)
     i=2
(11)

where u(φi-1i) is the pair interaction energy, and bonds are not energetically independent. We calculate the partition function by summing over all configurational states represented by the set of {φi}, after which the thermodynamic functions follow in the usual manner.

       ∑
Z   =      exp (- U (φi)∕kT)
       {φi}
Fp  =  - kT ln Z
S   =  - ∂F ∕∂T
 p         p
U   =  Fp + TSp                                       (12)
